Fullex SL16 Gearbox for Multipoint Door Lock

Multipoint Door Lock Replacement Gearbox Only Fullex SL16 UPVC 35mm Backset 68PZ

This SL16 replacement gearbox is designed to fit Fullex locks. Commonly this is the part that is most likely to be at fault when a lock fails and becomes unusable. Replacing the gearbox is cost effective as it saves having to buy a complete new lock and it is quite easily achieved.

Fullex manufacture a range of door locks, as always taking careful measurements will ensure a correct fit. The latch is easily reversible to fit both left and right handed doors, it is designed for use with lever/lever or lever/pad handles.

Features:

• Lever/ Lever or Lever/Pad split spindle handle operation
• Non Handed - fits both left and right handed doors

What's in the pack?

1 x Multipoint Door Lock Replacement Gearbox Only Fullex SL16 UPVC 35mm Backset 68PZ

Dimensions:

• Lock case length: 264mm
• Lock case width: 16mm
• Latch projection: 16mm
• Deadbolt Length: 30mm
• Deadbolt Thickness: 6mm
• Centre of latch to centre of deadbolt: 90mm
• Distance between faceplate screw holes: 208mm
• PZ: 68mm
• Backset: 35mm

Please see technical diagram in gallery.

What should I check before ordering a new door lock gearbox case?

The most important measurements are the backset and the lock handle centres (the distance from the centre of the handle spindle to the centre of the barrel). Both measurements should be checked before ordering to ensure compatibility.

Please see technical diagram in gallery.
