Mila Coldseal Gearbox for Multipoint Door Lock Single Spindle

Multipoint Door Lock Gearbox Case Only Mila Coldseal Swift Frame UPVC 35mm Backset 92PZ 92mm Single Spindle

The Multipoint Door Lock Gearbox Mila Coldseal is the perfect replacement part for restoring security and function to your UPVC door. When a multipoint lock fails, it’s often the gearbox that’s at fault rather than the entire mechanism. Instead of replacing the whole lock, this cost-effective solution allows you to swap out just the faulty gearbox, saving time and money. Designed with a 35mm backset and 92PZ single spindle, it is compatible with Mila, Coldseal, and Swift Frame multipoint door locks, ensuring a seamless fit when properly measured.

Engineered for convenience, this gearbox case is non-handed, meaning it can be installed on both left and right-handed doors. It works with lever/lever handles, making it a versatile and practical choice for homeowners and professionals alike. Whether you're tackling a DIY repair or a trade installation, this replacement gearbox restores smooth locking operation without the need for a full lock replacement.

Benefits:

• Cost-Effective Repair Solution – Instead of replacing the entire multipoint lock, swapping out just the gearbox saves money while restoring full locking functionality.
• Easy Installation & Universal Fit – Designed to fit Mila, Coldseal, and Swift Frame multipoint locks, this replacement gearbox ensures a hassle-free swap when measured correctly.
• Non-Handed for Versatile Use – With an adaptable latch, this gearbox can be installed on both left and right-handed doors, making it a convenient choice for any setup.
• Compatible with Lever/Lever Handles – Specifically designed for use with lever/lever handle operation, ensuring smooth and reliable function with standard UPVC door handles.
• Reliable & Durable Construction – Built to last, this gearbox restores secure locking performance, giving your door a longer lifespan without the need for a complete lock replacement.

What's in the pack?

1 x Mila Coldseal Swift Frame replacement 35mm Gearbox

Dimensions:

• Lock case length: 233mm
• Lock case depth: 50mm
• Lock case width: 13mm
• Deadbolt length: 30mm
• Deadbolt thickness: 5mm
• Centre of latch to centre of deadbolt: 103mm
• PZ: 92mm
• Backset: 35mm
• Distance between faceplate screw holes: 197mm

All measurements are approximate.

Please refer to the diagram in gallery.

Frequently Asked Questions:

1. How do I know if this gearbox will fit my door lock?
   The most important step is to check the backset measurement (35mm) and the PZ centre measurement (92mm) to ensure compatibility with your existing multipoint lock. Additionally, confirming that your current lock is a Mila, Coldseal, or Swift Frame model will help ensure a perfect fit.

2. What tools will I need to replace the gearbox?
   Typically, you’ll need a screwdriver to remove the screws securing the old gearbox and a tape measure to double-check fitting dimensions (please make sure your measurements match before buying your new gearbox). The replacement process is straightforward and can be done without professional help, making it a great DIY-friendly repair.

3. How do I reverse the latch for left or right-handed doors?
   This gearbox is non-handed, meaning the latch can be reversed to suit left or right-handed door installations. To do this:

   • Locate the cross-head screw on the side of the gearbox, inline with the latch.
   • Unscrew and remove the screw.
   • Pull out the latch, rotate it 180°, and reinsert it.
   • Replace the screw securely to hold the latch in place.
     This simple adjustment ensures the gearbox works with your door's existing handing.
